Specs
- MODEL ARCMI - 09 / ARCMO - 09
- 9,000
- Cooling Capacity 2.64 kWatt
- EER 3.10 W / W
- Voltage / Frequency / Phase 230 / 50 / 1 V / Hz / Ph
- Current Input-Cooling 3.7 A
- Power Input-Cooling 850 W
- Air Flow Volume (Hi / Med / Low) 556 / 445 / 338 m³ / h
- Noise Level-Indoor Unit 30 / 35 / 41 (db(A))
- Noise Level-Outdoor Unit 55 (db(A))
- Compressor Type ROTARY
- Liquid line / Gas line 1 / 4” / 3 / 8”
- Dimensions -Indoor Unit WxDxH 802 × 297 × 189 mm
- Dimensions - Outdoor Unit WxDxH 770 × 555 × 300 mm
- Net Weight Indoor / Outdoor 8.5 / 27.0 kg
- Refrigerant R410A / 600g
- Operation Temperature Range-Cooling 18~43 ͦC
- Loading Quantities per 20’ / 40’HC 105 / 248
- MODEL ARCMI - 12 / ARCMO - 12
- 12,000
- Cooling Capacity 3.52 kWatt
- EER 3.5 W / W
- Voltage / Frequency / Phase 230 / 50 / 1 V / Hz / Ph
- Current Input-Cooling 4.4 A
- Power Input-Cooling 1,005 W
- Air Flow Volume (Hi / Med / Low) 609 / 480 / 365 m³ / h
- Noise Level-Indoor Unit 32 / 37 / 42 (db(A))
- Noise Level-Outdoor Unit 55 (db(A))
- Compressor Type ROTARY
- Liquid line / Gas line 1 / 4” / 1 / 2”
- Dimensions -Indoor Unit WxDxH 802 × 297 × 189 mm
- Dimensions - Outdoor Unit WxDxH 770 × 555 × 300 mm
- Net Weight Indoor / Outdoor 9.0 / 29.0 kg
- Refrigerant R410A / 680g
- Operation Temperature Range-Cooling 18~43 ͦC
- Loading Quantities per 20’ / 40’HC 105 / 248
- MODEL ARCMI - 18 / ARCMO - 18
- 18,000
- Cooling Capacity 5.28 kWatt
- EER 3.10 W / W
- Voltage / Frequency / Phase 230 / 50 / 1 V / Hz / Ph
- Current Input-Cooling 7.4 A
- Power Input-Cooling 1,700 W
- Air Flow Volume (Hi / Med / Low) 822 / 623 / 491 m³ / h
- Noise Level-Indoor Unit 34 / 39 / 47 (db(A))
- Noise Level-Outdoor Unit 60 (db(A))
- Compressor Type ROTARY
- Liquid line / Gas line 1 / 4” / 1 / 2”
- Dimensions -Indoor Unit WxDxH 965 × 319 × 215 mm
- Dimensions - Outdoor Unit WxDxH 770 × 555 × 300 mm
- Net Weight Indoor / Outdoor 11.5 / 35.0 kg
- Refrigerant R410A / 920g
- Operation Temperature Range-Cooling 18~43 ͦC
- Loading Quantities per 20’ / 40’HC 90 / 210
- MODEL ARCMI - 24 / ARCMO - 24
- 22,000
- Cooling Capacity 6.45 kWatt
- EER 3.10 W / W
- Voltage / Frequency / Phase 230 / 50 / 1 V / Hz / Ph
- Current Input-Cooling 9.0 A
- Power Input-Cooling 2,080 W
- Air Flow Volume (Hi / Med / Low) 1.197 / 973 / 885 m³ / h
- Noise Level-Indoor Unit 42 / 45 / 50 (db(A))
- Noise Level-Outdoor Unit 59 (db(A))
- Compressor Type ROTARY
- Liquid line / Gas line 3 / 8” / 5 / 8”
- Dimensions -Indoor Unit WxDxH 1.080 × 335 × 226 mm
- Dimensions - Outdoor Unit WxDxH 845 × 702 × 363 mm
- Net Weight Indoor / Outdoor 14.5 / 42.5 kg
- Refrigerant R410A / 1.100g
- Operation Temperature Range-Cooling 18~43 ͦC
- Loading Quantities per 20’ / 40’HC 66 / 152
Benefits
Auto Error Diagnosis
Once abnormal operation or parts failure happens, the unit will shut off automatically to protect the system. Meanwhile it will indicate protection or error code for fast service.
Auto Restart
If the air conditioner breaks off unexpectedly due to the power cut, it will restart with the previous setting mode automatically when the power resume.
More
Louver Position Memory
Horizontal louver will automatically move to the same position as you set last time when the unit turned on
Refrigerant Leakage Detect
Indoor unit will show error code “EC” and will stop automatically when refrigerant leakage is detected
Auto Swing Louver
Distributes cool/warm air to maximum area by moving horizontal flaps automatically.
Two-way Draining
Both left and right sides of the indoor unit are possible for drainage hose connection, easy for installation.
